Product Type:PLC

Product ID:1785-L20B

Allen-Bradley Type Designation:PLC-5/20

Memory:16K words

Maximum User Memory:16K words

Maximum Total I/O:512 any mix or 512 in + 512 out (complement)

Channels:1 DH+, 1 DH+/remote I/O

Maximum Number of I/O Chassis:13 (Total) 12 (Remote)

Module Type:Standard Processor

Remote I/O:12 chassis

Backplane current load:2.3 A

Processor:PLC-5/20

Extended Product Type:Standard Processor Module

Voltage:Not specified

Phase:3

Amps:Not specified

kW:Not specified

HP:Not specified

Frame:Not specified

Enclosure:Panel Mount – IP 20, NEMA/UL Type 1

Interface Module:Prog. Only LCD

Manual:No

IGBT:Yes

Resistor:No

Rating:Filtered A & B Frames (Optional) C, D, & E Frames (Standard)

    Engineered for robust performance, the ABB 1785-L20B PLC-5/20 Controller is a cornerstone of modern industrial automation. It boasts a compact design and a comprehensive feature set tailored for precision control tasks.

    This PLC module is capable of managing up to 512 input/output channels, ensuring versatile connectivity and data handling for diverse industrial processes. Its integrated 16K word SRAM memory supports extensive program storage and runtime operations.

    With support for ControlNet (coax) network technology, the controller facilitates efficient data exchange between various components of a factory floor, enhancing overall system performance and reliability.

    The 1785-L20B comes equipped with a high-resolution LCD display for intuitive operation and monitoring. Its user-friendly interface simplifies programming and diagnostics, streamlining maintenance and troubleshooting.

    Equipped with advanced filtering capabilities for A & B frames (optional), and standard C, D, & E frames, the controller ensures smooth operation under varying environmental conditions. This robust design is complemented by its Panel Mount – IP 20, NEMA/UL Type 1 enclosure, offering protection against dust, water, and other contaminants.
