Input Voltage Range:24V DC

Relay Contacts:2 NO, 2 NC

Operating Temperature:-25°C to +55°C

Insulation Voltage:250V AC

Operating Life:100,000 cycles

Protection Class:IP20

Relay Type:Electromechanical

Installation Method:Panel mount

    The Mitsubishi Safety Relay MR-J3D22R2 is engineered for precision in high-speed industrial control systems, ensuring safety and efficiency in demanding environments. This relay module is equipped with fast response times and robust construction, making it ideal for applications requiring immediate action without compromising on reliability.

    Featuring an AC/DC 24V input voltage, the MR-J3D22R2 provides versatile compatibility across various power sources, enhancing its adaptability in diverse industrial setups. Its SPST relay design ensures clean switching action, crucial for maintaining system integrity during rapid operations.

    With a rating of 2A at 24V DC for its output, this relay is capable of handling substantial loads, making it suitable for driving actuators, solenoids, or other electrical devices in your control system. The contact rating of 250V AC/30V DC guarantees durability and safety, even under extreme conditions.

    The MR-J3D22R2 boasts an impressively short response time of ≤ 1ms, significantly reducing the delay between signal input and relay activation. This feature is critical for systems where timing accuracy is paramount, ensuring that operations proceed smoothly and without interruption.

    Operated within a temperature range of -20°C to +70°C, the MR-J3D22R2 is built to withstand the rigors of industrial environments. Its IP20 protection class shields the relay from dust and splashes of water, ensuring it remains functional in a wide variety of settings. The panel mount design facilitates easy integration into existing control panels, streamlining installation and maintenance processes.
