Component Material:High-grade copper-clad laminate

Board Size:120mm x 100mm

Power Supply Voltage:DC 5V

Operating Temperature Range:-40°C to +85°C

Communication Interface:RS-485

Load Capacity:Up to 2A per channel

Reliability Rating:MTBF > 100,000 hours

    This Feedback PCB Board from ABB is meticulously designed for seamless integration into complex industrial control environments. It leverages advanced surface mount technology (SMT) for robust construction and superior heat dissipation, ensuring reliability even under extreme conditions.

    Equipped with high-grade FR4 epoxy glass material, this PCB board offers exceptional durability and resistance against electrical noise, guaranteeing precise signal transmission over its operational life.

    With an operating temperature range from -40°C to +85°C, it withstands harsh industrial environments, from freezing cold storage areas to scorching hot production floors. This wide temperature tolerance ensures consistent performance across various settings.

    Featuring a compact size of 120mm x 75mm, the board efficiently utilizes space without compromising on functionality. Its compact design makes it an ideal choice for retrofit applications or new installations requiring minimal footprint.

    The board supports a maximum current rating of 5A at 24V DC, providing ample power for a wide range of feedback signals in industrial systems. This compatibility ensures that it can handle diverse applications within the automation sector.
